A lightweight chain saw for professional arborists . For in-tree professional use only.
MS 192 T STIHL CHAINSAW 12 & 14 inch { fan cover side }
CLICK HERE TO ENLARGE
At only 3.1 kilograms, this top-handle saw provides a lightweight ally as you climb to the sky. Excellent power to weight. To perform very accurate. Recoilless start thanks to microprocessor controlled ignition, optimal ergonomics. This is specially designed for working in the tree and is only applicable in the tree care. This chain saw is intended for users trained in arboriculture.When the weight of your saw matters, the MS 192 T C-E delivers
MS 192 T STIHL CHAINSAW 12 & 14 inch { bar cover side }
 CLICK HERE TO ENLARGE
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (1) Power to weight ratio kg / kW Saw chain Pitch STIHL Oilomatic chain saw type Sound pressure level dB(A) (2) Sound power level in dB(A)(2) Vibration value left/right/s² (3) |
30.1 1.3 / 1.8 3.1 2.4 3/8 "P Picco Micro Mini (PMM) 97.0 109.0 2,9 / 3,1 |
(1) without bar/chain
(2) K-factor Directive 2006/42/EC according to 2.5 DB(a)) =
(3) K-factor Directive 2006/42/EC according to = 2 m/s²
(2) K-factor Directive 2006/42/EC according to 2.5 DB(a)) =
(3) K-factor Directive 2006/42/EC according to = 2 m/s²
|
|
|
|
|
MS 192 T
|
|
A lightweight chain saw for professional arborists . For in-tree professional use only.
Tool-less tank lid:
CLICK HERE TO ENLARGE
Tool free filler caps
Special catches on the fuel and oil tanks for easy opening and locking without
the need for tools
(Similar to picture)
More information
Special catches on the fuel and oil tanks for easy opening and locking without
the need for tools
(Similar to picture)
More information
Lateral chain tensioning :
CLICK HERE TO ENLARGE
Side chain tensioner
The tensioning screw can be found on the side of chain saw through the sprocket cover.
This removes the need for contact with the sharp saw chain.
(Similar to picture)
The tensioning screw can be found on the side of chain saw through the sprocket cover.
This removes the need for contact with the sharp saw chain.
(Similar to picture)
Anti vibration system:
CLICK HERE TO ENLARGE
In the longer term, strong vibrations at the handle points
of motor equipment can lead to poor circulation in hands and
arms. STIHL has therefore developed a high quality anti vibration system.Motor
devices with AV system, the vibrations generated by the engine and the
working environment, be substantially reduced at the handle points.
(Similar to picture)
of motor equipment can lead to poor circulation in hands and
arms. STIHL has therefore developed a high quality anti vibration system.Motor
devices with AV system, the vibrations generated by the engine and the
working environment, be substantially reduced at the handle points.
(Similar to picture)
STIHL Ematic system:
CLICK HERE TO ENLARGE
Ematic chain lubrication system
The Ematic chain lubrication system ensures pinpoint lubrication of the saw chain
links and guide bar rails. When used with STIHL OILOMATIC saw chain, it will provide
maximum lubrication, longer wear and less oil consumption than conventional methods
of chain lubrication. The Ematic system can reduce bar oil consumption by up to 50%
The Ematic chain lubrication system ensures pinpoint lubrication of the saw chain
links and guide bar rails. When used with STIHL OILOMATIC saw chain, it will provide
maximum lubrication, longer wear and less oil consumption than conventional methods
of chain lubrication. The Ematic system can reduce bar oil consumption by up to 50%
Compensator:
CLICK HERE TO ENLARGE
The STIHL compensator, a control system in the carburettor, ensures
that despite increasing pollution of the air filter engine performance, exhaust
quality and fuel consumption over a long period remain almost constant.
Only when a noticeable performance degradation occurs,
the air filter must be cleaned. So, very long working
intervals without maintenance are possible. (Similar to picture)
that despite increasing pollution of the air filter engine performance, exhaust
quality and fuel consumption over a long period remain almost constant.
Only when a noticeable performance degradation occurs,
the air filter must be cleaned. So, very long working
intervals without maintenance are possible. (Similar to picture)
Single-lever operation:
CLICK HERE TO ENLARGE
The functions of the machine, such as cold and warm startup,
operation and stop, are controlled by a single lever. This makes
the operation especially comfortable and safe, because the right hand
on the handle can remain. (Similar to picture)
operation and stop, are controlled by a single lever. This makes
the operation especially comfortable and safe, because the right hand
on the handle can remain. (Similar to picture)
Additional features:
STIHL ElastoStart :
CLICK HERE TO ENLARGE
STIHL ElastoStart reduces the shock caused by the compression of the engine
during starting. The compression shock is taken away from the user's joints and
muscles through a spring or rubber element in the starter handle.
(Similar to picture)
More information
during starting. The compression shock is taken away from the user's joints and
muscles through a spring or rubber element in the starter handle.
(Similar to picture)
More information
