Powerful professional 0.95kW brushcutter with 4-MIX-Engine

                                                    FS 90

CLICK HERE TO ENLARGE

Robust brushcutter for demanding and frequent applications. With the patented STIHL 4-MIX engine providing fast acceleration, more power, added torque, lower noise and increased fuel efficiency when compared to a 2-stroke engine. With a rigid drive shaft suitable for extended use and fully adjustable tool free handle. Suitable for use with a variety of cutting attachments to tackle large areas, tough weed, gnarled shrubbery and thinning of small trees.

---

CLICK HERE TO ENLARGE

Specifications :

Displacement cm ³
Power  kW / hp
Weight kg  (2)
Cutting blade
Fuel capacity l
Overall length m (3)
Sound pressure level dB(A) (4)
Sound power level in dB(A)(4)
Vibration levels left/right with metal blade m/s²(1)
Vibration levels left/right m/s² (1)

28.4
0.95 / 1.3
5.8
AutoCut C 25-2 Head
0.53
1.8
91.0
101.0
5.3/6.1
4.6/5.4

(1) (K) factor according to Dir. 2006/42/EC = 2m/s²
(2) without cutting tool and deflector
(3) without tool
(4) Power factor according to DIR2006/42/EC=2.5(dB(A))

---

---

 FS 90
Standard equipment:

Powerful professional 0.95kW brushcutter with 4-MIX-Engine

Double shoulder harness :

CLICK HERE TO ENLARGE

Soft padding makes work more comfortable during longer jobs.

---

STIHL 4-MIX-Motor :

CLICK HERE TO ENLARGE

You can always rely on STIHL to keep setting new benchmarks this time with 4-stroke
mixed lubrication technology. The STIHL 4-MIX engine, which runs on a fuel-oil mix just
 like a 2-stroke, offers the benefits without the compromises of 4-stroke power. STIHL
4-MIX engine technology provides fast acceleration, more power, added torque, lower
noise, reduced emissions and increased fuel efficiency to complete jobs quickly, quietly
and more easily.

---

Anti-vibration system :

CLICK HERE TO ENLARGE

Intense vibration at the handles of power tools can lead to long-term effects on blood
vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration
system whereby the oscillations from the machine's engine are dampened which
significantly reduces vibrations at the handles.

---

Bike handle :

CLICK HERE TO ENLARGE

When used in conjunction with a harness, the bike handle enables a smooth mowing action.
The bike handle allows the machine to be easily guided, making it ideal for working on large
areas and thus reducing fatigue.

---

Multi-function control handle :

CLICK HERE TO ENLARGE

Easy, comfortable thumb-operated control means the operator's hand never
leaves the handle.

---

Decompression system :

CLICK HERE TO ENLARGE

The decompression system allows some of the compression pressure in the cylinder to
escape, so less force on the starter rope is needed.

---

• Tool free handle adjustment :


CLICK HERE TO ENLARGE

The central wing nut enables easy adjustment without the use of tools. For transportation and space-saving storage, the handle can be rotated by 90°.

---

Manual fuel pump (purger) :

CLICK HERE TO ENLARGE

A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.

More information

---

---

Additional features :

ADVANCE PLUS Universal harness :

CLICK HERE TO ENLARGE

Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.

---

We present some Product Technology features in STIHL product technology .

NOTE: Deviations from this range and these data are possible depending on the country. Changes in technology, equipment, price and range of accessories are reserved
