Simple to start and perfectly balanced light brushcutter
FS 50
CLICK HERE TO ENLARGE
New lightweight brushcutter with simplified starting procedure. Handle with thumb screw. Very good trim the lawn and trimming jobs around trees, paths and stairs to the private garden plot.
 CLICK HERE TO ENLARGE
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (1) Cutting blade Overall length M (3) Fuel capacity l Sound pressure level dB(A) (2) Sound power level in dB(A)(2) Vibration value left/right/s² (4) |
27.2 0.8/1.1 4.4 Mowing head AutoCut C 1.45 0.34 93.0 105.0 6.0/5.7 |
CLICK HERE TO ENLARGE
|
(1) without cutting tool and deflector (2) (K) factor according to Dir. 2006/42/EC = 2m/s² (3) without tool (4) Power factor according to DIR2006/42/EC=2.5(dB(A)) |
|
|
FS 50
|
|
Simple to start and perfectly balanced light brushcutter
Reduced-emission engine technology :
CLICK HERE TO ENLARGE
2-stroke engine with stratified charge. A fuel-free layer of air is created between the
burned charge in the combustion chamber and the fresh charge in the crankcase,
reducing the amount of fuel lost during the charge cycle. This results in more power
with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines
and significantly reduced exhaust emissions.
More information
burned charge in the combustion chamber and the fresh charge in the crankcase,
reducing the amount of fuel lost during the charge cycle. This results in more power
with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines
and significantly reduced exhaust emissions.
More information
Simplified starting system :
CLICK HERE TO ENLARGE
Simply set the choke, pump the fuel primer, pull the starter cord and away you go! The
running machine then switches off after a brief press of the stop button. Once the machine
is at a standstill, the ignition activates again automatically. Thus the ignition is always ready
for starting.
running machine then switches off after a brief press of the stop button. Once the machine
is at a standstill, the ignition activates again automatically. Thus the ignition is always ready
for starting.
Single-lever :
CLICK HERE TO ENLARGE
The patented special closure for the fuel tank. The tanks so that the engine-equipped devices
can be quickly opened without much effort and without tools and close again. Level control by
transparent tank.
(Illustration similar)
Loop handle (R) :
CLICK HERE TO ENLARGE
The loop handled grass trimmers and brushcutters are ideal for working in areas where
space is limited, e.g. thinning between bushes and shrubs
space is limited, e.g. thinning between bushes and shrubs
Multi-function control handle :
CLICK HERE TO ENLARGE
Easy, comfortable thumb-operated control means the operator's hand never leaves the
handle.
handle.
Manual fuel pump (purger) :
CLICK HERE TO ENLARGE
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.
More information
number of starting pulls required following extended breaks in operations.
More information
Additional features :
Carrying harness :
CLICK HERE TO ENLARGE
Carrying strap As standard, soft padded shoulder strap, which makes working longer more
relaxed, more comfortable and safer.
relaxed, more comfortable and safer.
ADVANCE PLUS Universal harness :
CLICK HERE TO ENLARGE
Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.
saw.
STIHL ErgoStart (E) :
CLICK HERE TO ENLARGE
STIHL ErgoStart (E) Lightweight and strength when starting with an additional
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
Shoulder strap / carrying system :
CLICK HERE TO ENLARGE
Using a STIHL shoulder strap or carrying harness with soft padding makes work
more comfortable, particularly during lengthy jobs.
more comfortable, particularly during lengthy jobs.
