Professional hedge trimmer for cutting back with single-sided blade
HS 86 T, 30 inch
CLICK HERE TO ENLARGE
Professional hedge trimmer with single-sided blade for trimming applications. Low weight and low vibrations. Especially coordinated gear ratio with up to 5000 strokes per minute. High blade speed and a finer cut.
CLICK HERE TO ENLARGE
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (1) Cutting blade length cm Total length cm Tooth spacing mm Sound pressure level dB(A) (2) Sound power level in dB(A)(2) Vibration value left/right/s² (3) Blade Strokes 1/min |
22.7 0.7/1.0 5.2 75 124 38 94.0 104.0 2.5/3.0 5000 |
|
(1) (with blade, without fuel)
(2) (K) factor according to Dir. 2006/42/EC = 2m/s² (3) Power factor according to DIR2006/42/EC=2.5(dB(A)) |
|
|
HS 86 T
|
|
Professional hedge trimmer for cutting back with single-sided blade
Anti-vibration system :
CLICK HERE TO ENLARGE
Intense vibration at the handles of power tools can lead to long-term effects on blood vessels
in the hands and arms. STIHL has therefore developed an effective anti-vibration system
whereby the oscillations from the machine's engine are dampened which significantly reduces
vibrations at the handles.
in the hands and arms. STIHL has therefore developed an effective anti-vibration system
whereby the oscillations from the machine's engine are dampened which significantly reduces
vibrations at the handles.
Trimming variation (T) :
CLICK HERE TO ENLARGE
The T variations of STIHL hedge trimmers provide the perfect trimming and shaping of hedges
and shrubs. Thanks to the blade shape with smaller tooth spacing and lower tooth height in
conjunction with the gearing for a high stroke rate, more specific shapes can also be achieved.
and shrubs. Thanks to the blade shape with smaller tooth spacing and lower tooth height in
conjunction with the gearing for a high stroke rate, more specific shapes can also be achieved.
Sided cutting blade :
CLICK HERE TO ENLARGE
The STIHL hedge trimmer with single-sided blade are suitable for horizontal cuts in always the
same amount. Due to the one-sided knife they are still somewhat easier than equipped with
double-sided cutting blades hedge trimmers. (Illustration similar)
same amount. Due to the one-sided knife they are still somewhat easier than equipped with
double-sided cutting blades hedge trimmers. (Illustration similar)
Sided ground blade :
CLICK HERE TO ENLARGE
The double-sided cutting blade is ground on one side. The special blade geometry ensures
high cutting performance. (Illustration similar)
high cutting performance. (Illustration similar)
Blade protection :
CLICK HERE TO ENLARGE
The comfort models HS 81 R and HS 86 R come standard with a blade protection, which
prevents damage to both blade and gear, but also to hard elements (eg natural stone wall).
This also facilitates cutting close to the ground ground cover.
(Illustration similar)
prevents damage to both blade and gear, but also to hard elements (eg natural stone wall).
This also facilitates cutting close to the ground ground cover.
(Illustration similar)
Long-life air filter system :
CLICK HERE TO ENLARGE
Provides long intervals between cleaning and reliable protection of the engine.
(Illustration similar)
(Illustration similar)
Tool free filler cap :
CLICK HERE TO ENLARGE
Patented special fuel and oil tank. The tanks so that the engine-equipped devices can be quickly
opened without effort and without tool and resealing
(similar to Fig.)
More information
opened without effort and without tool and resealing
(similar to Fig.)
More information
Electronic ignition module :
CLICK HERE TO ENLARGE
This ensures reliable starting and trouble-free running. The ignition system is fully encapsulated
and thus protected from damp and dirt.
and thus protected from damp and dirt.
Manual fuel pump :
CLICK HERE TO ENLARGE
With the manual fuel pump delivers fuel to thumb pressure to the carburetor. This is the
machine after an extended idle period reduces the number of starting strokes (similar).
More information
machine after an extended idle period reduces the number of starting strokes (similar).
More information
Hanging loop in the handle :
CLICK HERE TO ENLARGE
Integrated into the housing for attaching to the wall mount. This makes the machine safely
and compactly store can be (similar).
and compactly store can be (similar).
We present some Product Technology features in STIHL product technology .
NOTE: Deviations from this range and these data are possible depending on the country. Changes in technology, equipment, price and range of accessories are reserved
|
|
|
|
|
