Modern, convenient and very easy to start. Ideal for around-the-garden trimming tasks.

                                                        FS 40

CLICK HERE TO ENLARGE

The lightest brushcutter of the new generation. Modern appearance, convenient operation and very simple starting procedure are the highlights of the new generation STIHL grass trimmer range. The number of steps needed to start the machine has been drastically reduced. The frustration of a flooded engine is virtually eliminated. New 2-stroke engine with stratified charge allows fast acceleration, low emissions, reduced fuel consumption. With bent shaft, loop handle and AutoCut mowing head ideally for trimming small areas of grass and around obstacles

---

CLICK HERE TO ENLARGE



---

Specifications :

Displacement cm ³
Power  kW / hp
Weight kg  (1)
Cutting blade
Overall length M (3)
Fuel capacity l
Sound pressure level dB(A) (2)
Sound power level in dB(A)(2)
Vibration value left/right/s² (4)

27.2
0.7/1.0
4.4
AutoCut mowing head
1.45
0.34
94.0
103.0
7.0/6.4

CLICK HERE TO ENLARGE

(1) without cutting tool and deflector
(2) (K) factor according to Dir. 2006/42/EC = 2m/s²
(3) without tool
(4) Power factor according to DIR2006/42/EC=2.5(dB(A))

---

---

 FS 40
Standard equipment:

Modern, convenient and very easy to start. Ideal for around-the-garden trimming tasks.

Reduced-emission engine technology :

CLICK HERE TO ENLARGE

2-stroke engine with stratified charge. A fuel-free layer of air is created between the
burned charge in the combustion chamber and the fresh charge in the crankcase,
reducing the amount of fuel lost during the charge cycle. This results in more power
with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines
and significantly reduced exhaust emissions.

More information

---

Simplified starting system :

CLICK HERE TO ENLARGE

Simply set the choke, pump the fuel primer, pull the starter cord and away you go! The
running machine then switches off after a brief press of the stop button. Once the machine
is at a standstill, the ignition activates again automatically. Thus the ignition is always ready
 for starting.

---

Single-lever :

CLICK HERE TO ENLARGE

The patented special closure for the fuel tank. The tanks so that the engine-equipped devices
can be quickly opened without much effort and without tools and close again. Level control by
transparent tank.
(Illustration similar)

---

Loop handle (R) :

CLICK HERE TO ENLARGE

The loop handled grass trimmers and brushcutters are ideal for working in areas where
space is limited, e.g. thinning between bushes and shrubs

---

Multi-function control handle :

CLICK HERE TO ENLARGE

Easy, comfortable thumb-operated control means the operator's hand never leaves the
handle.

---

Manual fuel pump (purger) :

CLICK HERE TO ENLARGE

A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.

More information

---

---

Additional features :

Carrying harness :

CLICK HERE TO ENLARGE

Carrying strap As standard, soft padded shoulder strap, which makes working longer more
relaxed, more comfortable and safer.

---

Shoulder strap / carrying system :

CLICK HERE TO ENLARGE

Using a STIHL shoulder strap or carrying harness with soft padding makes work
more comfortable, particularly during lengthy jobs.

---

STIHL ErgoStart (E) :

CLICK HERE TO ENLARGE

STIHL ErgoStart (E) Lightweight and strength when starting with an additional
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.

More information

---

We present some Product Technology features in STIHL product technology .

NOTE: Deviations from this range and these data are possible depending on the country. Changes in technology, equipment, price and range of accessories are reserved
