Extremely powerful 1.4kW-Brushcutter with 4-MIX engine

                                                    FS 130

CLICK HERE TO ENLARGE

The STIHL 4-MIX engine is the first four stroke engine which works on a mixture of petrol and oil. It combines the advantages of four-stroke and two-stroke engines in one. With higher torque and up to 80% less emissions and a deeper more pleasant sound. Easy to start due to the decompression system and manual fuel pump. Supplied fitted with AutoCut and Metal blade cutting heads. For professional users with high demands.

---

CLICK HERE TO ENLARGE

Specifications :

Displacement cm ³
Power  kW / hp
Weight kg  (2)
Cutting blade
Fuel capacity l
Overall length m (3)
Sound pressure level dB(A) (4)
Sound power level in dB(A)(4)
Vibration levels left/right with metal blade m/s²(1)
Vibration levels left/right m/s² (1)

36.3
1.4 / 1.9
5.9
AutoCut C 25-2 Head
0.53
1.8
94.0
106.0
4.4/3.9
4.5/3.7

(1) (K) factor according to Dir. 2006/42/EC = 2m/s²
(2) without cutting tool and deflector
(3) without tool
(4) Power factor according to DIR2006/42/EC=2.5(dB(A))

---

---

 FS 130
Standard equipment:

Extremely powerful 1.4kW-Brushcutter with 4-MIX engine

Double shoulder harness :

CLICK HERE TO ENLARGE

Soft padding makes work more comfortable during longer jobs.

---

STIHL 4-MIX-Motor :

CLICK HERE TO ENLARGE

You can always rely on STIHL to keep setting new benchmarks this time with 4-stroke
mixed lubrication technology. The STIHL 4-MIX engine, which runs on a fuel-oil mix just
 like a 2-stroke, offers the benefits without the compromises of 4-stroke power. STIHL
4-MIX engine technology provides fast acceleration, more power, added torque, lower
noise, reduced emissions and increased fuel efficiency to complete jobs quickly, quietly
and more easily.

---

Anti-vibration system :

CLICK HERE TO ENLARGE

Intense vibration at the handles of power tools can lead to long-term effects on blood
vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration
system whereby the oscillations from the machine's engine are dampened which
significantly reduces vibrations at the handles.

---

Bike handle :

CLICK HERE TO ENLARGE

When used in conjunction with a harness, the bike handle enables a smooth mowing action.
The bike handle allows the machine to be easily guided, making it ideal for working on large
areas and thus reducing fatigue.

---

Multi-function control handle :

CLICK HERE TO ENLARGE

Easy, comfortable thumb-operated control means the operator's hand never
leaves the handle.

---

Decompression system :

CLICK HERE TO ENLARGE

The decompression system allows some of the compression pressure in the cylinder to
escape, so less force on the starter rope is needed.

---

• Tool free handle adjustment :


CLICK HERE TO ENLARGE

The central wing nut enables easy adjustment without the use of tools. For transportation and space-saving storage, the handle can be rotated by 90°.

---

Manual fuel pump (purger) :

CLICK HERE TO ENLARGE

A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.

More information

---

---

Additional features :

ADVANCE PLUS Universal harness :

CLICK HERE TO ENLARGE

Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.

---

We present some Product Technology features in STIHL product technology .

NOTE: Deviations from this range and these data are possible depending on the country. Changes in technology, equipment, price and range of accessories are reserved
