Very powerful 2.2kW-Clearing saw with M-Tronic (M) and ErgoStart (E)
FS 460 C-EM
CLICK HERE TO ENLARGE
STIHL's most advanced clearing saw ever, featuring the 'M-Tronic' fully electronic engine management system which adjusts ignition timing and fuel metering in all operating modes. With ErgoStart and simplified starting, the low emission 2-MIX engine and a 4 point anti-vibration system, the FS 460 C-EM is the ideal choice for anyone with large areas of tough overgrown grass to maintain.
CLICK HERE TO ENLARGE
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (2) Cutting blade Fuel capacity l Overall length m (3) Sound pressure level dB(A) (4) Sound power level in dB(A)(4) Vibration levels left/right with metal blade m/s²(1) Vibration levels left/right with plastic tool m/s² (1) |
45.6 2.2 / 3.0 8.5 Brush blade 300-3 0.75 1.79 101.0 110.0 1.9/1.6 2.5/2.1 |
(1) (K) factor according to Dir. 2006/42/EC = 2m/s²
(2) without cutting tool and deflector
(3) without tool
(4) Power factor according to DIR2006/42/EC=2.5(dB(A))
PRODUCT VIDEO :
|
|
FS 460 C-EM
|
|
Very powerful 2.2kW-Clearing saw with M-Tronic (M) and ErgoStart (E)
ADVANCE UNIVERSAL HARNESS :
CLICK HERE TO ENLARGE
Particularly ergonomic, comfortable and easy. For gentler forces mowing and chopping.
To expandable chest strap and tool bag.
STIHL M-Tronic :
CLICK HERE TO ENLARGE
This fully electronic engine management system adjusts ignition timing and fuel metering in
all operating modes. It also takes external conditions such as temperature, altitude and fuel
quality into account. It ensures consistent engine performance, a constant maximum speed
and superb acceleration. M-Tronic makes manual carburettor adjustments unnecessary.
Thanks to electronic cold/warm start recognition, now there is only one start position on the
combi-lever. The engine starts after fewer pulls and with no change of position, and can
immediately accelerate up to speed - even after a cold start. M-Tronic also remembers the
settings from the last time the tool was used. So when external conditions are the same,
optimal engine performance is available every time you start up again.
all operating modes. It also takes external conditions such as temperature, altitude and fuel
quality into account. It ensures consistent engine performance, a constant maximum speed
and superb acceleration. M-Tronic makes manual carburettor adjustments unnecessary.
Thanks to electronic cold/warm start recognition, now there is only one start position on the
combi-lever. The engine starts after fewer pulls and with no change of position, and can
immediately accelerate up to speed - even after a cold start. M-Tronic also remembers the
settings from the last time the tool was used. So when external conditions are the same,
optimal engine performance is available every time you start up again.
STIHL 2-MIX reduced-emission engine technology :
CLICK HERE TO ENLARGE
2-stroke engine with stratified charge. A fuel-free layer of air is created between
the burned charge in the combustion chamber and the fresh charge in the
crankcase, reducing the amount of fuel lost during the charge cycle. This results
in more power with a lower weight, up to 20% lower fuel consumption than regular
2-stroke engines and significantly reduced exhaust emissions.
More information
the burned charge in the combustion chamber and the fresh charge in the
crankcase, reducing the amount of fuel lost during the charge cycle. This results
in more power with a lower weight, up to 20% lower fuel consumption than regular
2-stroke engines and significantly reduced exhaust emissions.
More information
STIHL ErgoStart (E) :
CLICK HERE TO ENLARGE
STIHL ErgoStart (E) Lightweight and strength when starting with an additional
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
Bike handle :
CLICK HERE TO ENLARGE
When used in conjunction with a harness, the bike handle enables a smooth mowing action.
The bike handle allows the machine to be easily guided, making it ideal for working on large
areas and thus reducing fatigue.
The bike handle allows the machine to be easily guided, making it ideal for working on large
areas and thus reducing fatigue.
STIHL 4-point anti-vibration system :
CLICK HERE TO ENLARGE
STIHL brushcutters Steel springs reduce vibration damping units as the transmission of
vibrations generated by the engine and rotating cutting tool. The handles are thus extremely
low vibration and the devices can perform well. (Illustration similar)
vibrations generated by the engine and rotating cutting tool. The handles are thus extremely
low vibration and the devices can perform well. (Illustration similar)
Anti-vibration system :
CLICK HERE TO ENLARGE
Intense vibration at the handles of power tools can lead to long-term effects on blood
vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration
system whereby the oscillations from the machine's engine are dampened which
significantly reduces vibrations at the handles.
vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration
system whereby the oscillations from the machine's engine are dampened which
significantly reduces vibrations at the handles.
Locking the plug mandrel :
CLICK HERE TO ENLARGE
By locking the plug mandrel, the tool change is particularly simple. (Illustration similar)
Air filter with high life :
CLICK HERE TO ENLARGE
The easily accessible filter paper with high wear resistance ensures long intervals.
(Illustration similar)
Start flap lever (M-Tronic) :
CLICK HERE TO ENLARGE
Thanks to M-Tronic You must not know about cold or warm start know. With M-Tronic, there
are only a starting position at the starting flap lever. The system detects a cold or warm start
automatically and electronically calculated the exact amount of fuel. You start me less pulling
and can immediately apply full throttle. If you press the accelerator the start rotary switch will
automatically return to the operating position.
(Illustration similar)
are only a starting position at the starting flap lever. The system detects a cold or warm start
automatically and electronically calculated the exact amount of fuel. You start me less pulling
and can immediately apply full throttle. If you press the accelerator the start rotary switch will
automatically return to the operating position.
(Illustration similar)
Large fuel tank :
CLICK HERE TO ENLARGE
The transparent fuel tank with a volume of 0.75 l ensures long working periods with less
fuel stops. The level is easily visible from the outside. Easy filling through large, easily
accessible tank opening. (Illustration similar)
fuel stops. The level is easily visible from the outside. Easy filling through large, easily
accessible tank opening. (Illustration similar)
Winter slide :
CLICK HERE TO ENLARGE
The change from summer to winter operation is quick and easy means of a slide. In the
winter position of the air filter and carburetor icing is prevented. (Illustration similar)
Stop button :
CLICK HERE TO ENLARGE
The control of the stop switch when restarting is not necessary. The engine is always ready
to go. (Illustration similar)
Single-lever :
CLICK HERE TO ENLARGE
The patented special closure for the fuel tank. The tanks so that the engine-equipped devices
can be quickly opened without much effort and without tools and close again. Level control by
transparent tank.
(Illustration similar)
Multi-function control handle :
CLICK HERE TO ENLARGE
Easy, comfortable thumb-operated control means the operator's hand never
leaves the handle.
leaves the handle.
Compensator :
CLICK HERE TO ENLARGE
This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter
becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on
the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion
mixture constant and hence also the engine power. The filter doesn't need to be cleaned until
an appreciable drop in power occurs.
becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on
the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion
mixture constant and hence also the engine power. The filter doesn't need to be cleaned until
an appreciable drop in power occurs.
- Tool free handle adjustment :
CLICK HERE TO ENLARGE
The central wing nut enables easy adjustment without the use of tools. For transportation and
space-saving storage, the handle can be rotated by 90°.
space-saving storage, the handle can be rotated by 90°.
Manual fuel pump (purger) :
CLICK HERE TO ENLARGE
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.
More information
number of starting pulls required following extended breaks in operations.
More information
Additional features :
ADVANCE PLUS Universal harness :
CLICK HERE TO ENLARGE
Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.
saw.
