Robust 0.9 kW petrol brushcutter with ErgoStart and loop handle
FS 70 RC-E
CLICK HERE TO ENLARGE
Extremely robust 0.9 kW petrol brushcutter with loop handle. 2-MIX engine consumes up to 20% less fuel and 70% less emissions compared to conventional two-stroke engines without 2-MIX technology. ErgoStart simplified starting procedure for increased comfort. Optimised trimmer angle for working on large areas of tough grass.
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (1) Cutting blade Overall length M (3) Fuel capacity l Sound pressure level dB(A) (2) Sound power level in dB(A)(2) Vibration levels left/right with metal blade m/s² (1) Vibration levels left/right with plastic tool m/s² (1) |
27.2 0.9/1.2 4.8 AutoCut mowing head C 25-2 1.7 0.34 93.0 103.0 6.0/6.6 7.6/5.2 |
CLICK HERE TO ENLARGE
|
(1) without cutting tool and deflector (2) (K) factor according to Dir. 2006/42/EC = 2m/s² (3) without tool (4) Power factor according to DIR2006/42/EC=2.5(dB(A)) |
PRODUCT VIDEO No 1:
|
|
|
FS 70 RC-E
|
|
Robust 0.9 kW petrol brushcutter with ErgoStart and loop handle
Carrying harness :
CLICK HERE TO ENLARGE
Carrying strap As standard, soft padded shoulder strap, which makes working longer more
relaxed, more comfortable and safer.
relaxed, more comfortable and safer.
STIHL 2-MIX reduced-emission engine technology :
CLICK HERE TO ENLARGE
2-stroke engine with stratified charge. A fuel-free layer of air is created between
the burned charge in the combustion chamber and the fresh charge in the
crankcase, reducing the amount of fuel lost during the charge cycle. This results
in more power with a lower weight, up to 20% lower fuel consumption than regular
2-stroke engines and significantly reduced exhaust emissions.
More information
the burned charge in the combustion chamber and the fresh charge in the
crankcase, reducing the amount of fuel lost during the charge cycle. This results
in more power with a lower weight, up to 20% lower fuel consumption than regular
2-stroke engines and significantly reduced exhaust emissions.
More information
STIHL ErgoStart (E) :
CLICK HERE TO ENLARGE
STIHL ErgoStart (E) Lightweight and strength when starting with an additional
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
Loop handle (R) :
CLICK HERE TO ENLARGE
The loop handled grass trimmers and brushcutters are ideal for working in areas where
space is limited, e.g. thinning between bushes and shrubs
space is limited, e.g. thinning between bushes and shrubs
Simplified starting system :
CLICK HERE TO ENLARGE
Simply set the choke, pump the fuel primer, pull the starter cord and away you go!
The running machine then switches off after a brief press of the stop button. Once
the machine is at a standstill, the ignition activates again automatically. Thus the
ignition is always ready for starting.
The running machine then switches off after a brief press of the stop button. Once
the machine is at a standstill, the ignition activates again automatically. Thus the
ignition is always ready for starting.
Multi-function control handle :
CLICK HERE TO ENLARGE
Easy, comfortable thumb-operated control means the operator's hand never leaves the
handle.
handle.
Single-lever :
CLICK HERE TO ENLARGE
The patented special closure for the fuel tank. The tanks so that the engine-equipped devices
can be quickly opened without much effort and without tools and close again. Level control by
transparent tank.
(Illustration similar)
Manual fuel pump (purger) :
CLICK HERE TO ENLARGE
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.
More information
number of starting pulls required following extended breaks in operations.
More information
Additional features :
ADVANCE PLUS Universal harness :
CLICK HERE TO ENLARGE
Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.
saw.
Double shoulder harness :
CLICK HERE TO ENLARGE
Soft padding makes work more comfortable during longer jobs.
Shoulder strap / carrying system :
CLICK HERE TO ENLARGE
Using a STIHL shoulder strap or carrying harness with soft padding makes work more
comfortable, particularly during lengthy jobs.
comfortable, particularly during lengthy jobs.
