Simple to start and perfectly balanced light brushcutter with ErgoStart (E).
FS 50 C-E
CLICK HERE TO ENLARGE
New generation light ergonomic brushcutter with STIHL ErgoStart for easy jerk free starting. Ideal for tackling grassy areas around the garden or at the allotment. Modern appearance, convenient operation and very simple starting procedure are the highlights of the new generation STIHL grass trimmer range. The number of steps needed to start the machine has been drastically reduced. The frustration of a flooded engine is virtually eliminated. New 2-stroke engine with stratified charge allows fast acceleration, low emissions, reduced fuel consumption. With bent shaft, loop handle and AutoCut mowing head ideally for trimming small areas of grass and around obstacles. Ideal for edging as well as for small areas of grass. The loop handle can easily be adjusted for comfortable operation without the use of tools. Also available without STIHL ErgoStart easy-start system (FS 50).
 CLICK HERE TO ENLARGE
|
Specifications :
Displacement cm ³ Power kW / hp Weight kg (1) Cutting blade Overall length M (3) Fuel capacity l Sound pressure level dB(A) (2) Sound power level in dB(A)(2) Vibration value left/right/s² (4) |
27.2 0.8/1.1 4.5 AutoCut Mowing head 1.45 0.34 93.0 105.0 6.0/5.7 |
CLICK HERE TO ENLARGE
|
(1) without cutting tool and deflector (2) (K) factor according to Dir. 2006/42/EC = 2m/s² (3) without tool (4) Power factor according to DIR2006/42/EC=2.5(dB(A)) |
|
|
FS 50 C-E
|
|
Simple to start and perfectly balanced light brushcutter with ErgoStart (E).
Reduced-emission engine technology :
CLICK HERE TO ENLARGE
2-stroke engine with stratified charge. A fuel-free layer of air is created between the
burned charge in the combustion chamber and the fresh charge in the crankcase,
reducing the amount of fuel lost during the charge cycle. This results in more power
with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines
and significantly reduced exhaust emissions.
More information
burned charge in the combustion chamber and the fresh charge in the crankcase,
reducing the amount of fuel lost during the charge cycle. This results in more power
with a lower weight, up to 20% lower fuel consumption than regular 2-stroke engines
and significantly reduced exhaust emissions.
More information
STIHL ErgoStart (E) :
CLICK HERE TO ENLARGE
STIHL ErgoStart (E) Lightweight and strength when starting with an additional
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
spring between the crankshaft and Anwerfseilrolle. A quiet, steady train enough
to start reliably. Standard on all models with the designation CE.
More information
Simplified starting system :
CLICK HERE TO ENLARGE
Simply set the choke, pump the fuel primer, pull the starter cord and away you go! The
running machine then switches off after a brief press of the stop button. Once the machine
is at a standstill, the ignition activates again automatically. Thus the ignition is always ready
for starting.
running machine then switches off after a brief press of the stop button. Once the machine
is at a standstill, the ignition activates again automatically. Thus the ignition is always ready
for starting.
Single-lever :
CLICK HERE TO ENLARGE
The patented special closure for the fuel tank. The tanks so that the engine-equipped devices
can be quickly opened without much effort and without tools and close again. Level control by
transparent tank.
(Illustration similar)
Loop handle (R) :
CLICK HERE TO ENLARGE
The loop handled grass trimmers and brushcutters are ideal for working in areas where
space is limited, e.g. thinning between bushes and shrubs
space is limited, e.g. thinning between bushes and shrubs
Multi-function control handle :
CLICK HERE TO ENLARGE
Easy, comfortable thumb-operated control means the operator's hand never leaves the
handle.
handle.
Manual fuel pump (purger) :
CLICK HERE TO ENLARGE
A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the
number of starting pulls required following extended breaks in operations.
More information
number of starting pulls required following extended breaks in operations.
More information
Additional features :
Carrying harness :
CLICK HERE TO ENLARGE
Carrying strap As standard, soft padded shoulder strap, which makes working longer more
relaxed, more comfortable and safer.
relaxed, more comfortable and safer.
ADVANCE PLUS Universal harness :
CLICK HERE TO ENLARGE
Now with a new comfort carry ring for quickly attaching an removing the clearing
saw.
saw.
Shoulder strap / carrying system :
CLICK HERE TO ENLARGE
Using a STIHL shoulder strap or carrying harness with soft padding makes work
more comfortable, particularly during lengthy jobs.
more comfortable, particularly during lengthy jobs.
