STIHL MS181 Chainsaw - FLEMING'S STIHL Centre Naas Co. Kildare

STIHL MS 181
CHAINSAW

Stihl MS181
Chainsaw

PERFECT FOR AROUND-THE-GARDEN CUTTING JOBS

MS 181

Packed with new technology—at a value price—the STIHL MS 181 chain saw is designed to reduce vibrations, making it more comfortable to operate. This chain saw also features reduced-emission engine technology, which lowers fuel consumption as well as emissions; maintaining good cutting speed. Perfect for cutting firewood, for building work and for felling small trees.

Specifications :

Displacement cm ³ 31.8cm ³
Power  kW / hp   1.5 / 2.0
Weight kg 4.3kg(1)
Power to weight ratio kg / kW 2.9
Saw chain Pitch   3/8"P
STIHL Oilomatic chain saw type
Rapid micro mini 3 (PMM3)
Sound pressure level dB(A) 98.0(2)
Sound power level in dB(A) 109.0 (2)
Vibration value left/right/s²   4,0 / 3,5(3)

(1) without bar/chain
(2) K-factor Directive 2006/42/EC according to 2.5 DB(a)) =
(3) K-factor Directive 2006/42/EC according to = 2 m/s²

Owners / Instruction Manuals
MS181 Owners Manuel Click Here

Product Videos

STIHL MS 181
Standard equipment:

EASY TO START AND PERFECT FOR
AROUND-THE-GARDEN CUTTING JOBS

STIHL 2-MIX REDUCED-EMISSION ENGINE TECHNOLOGY :

CLICK HERE TO ENLARGE

2-stroke engine with stratified charge. A fuel-free layer of air is created between
the burned charge in the combustion chamber and the fresh charge in the
crankcase, reducing the amount of fuel lost during the charge cycle. This results
in more power with a lower weight, up to 20% lower fuel consumption than regular
2-stroke engines and significantly reduced exhaust emissions.

Anti vibration system:

CLICK HERE TO ENLARGE

Intense vibration at the handles of power tools can lead to long-term effects
on blood vessels in the hands and arms. STIHL has therefore developed an
effective anti-vibration system whereby the oscillations from the machine's
engine are dampened which significantly reduces vibrations at the handles.
(Similar to picture)

STIHL Ematic system:

CLICK HERE TO ENLARGE

The Ematic chain lubrication system ensures pinpoint lubrication of the saw
chain links and guide bar rails. When used with STIHL OILOMATIC saw chain,
it will provide maximum lubrication, longer wear and less oil consumption than
conventional methods of chain lubrication. The Ematic system can reduce bar
oil consumption by up to 50%

Compensator:

CLICK HERE TO ENLARGE

This controller in the carburettor prevents the fuel-air mixture getting richer as
the air filter becomes clogged. The correct quantity of fuel is delivered to the
carburettor depending on the quantity of air passing through the air filter. This
keeps the fuel/air ratio in the combustion mixture constant and hence also the
engine power. The filter doesn't need to be cleaned until an appreciable drop
in power occurs. (Similar to picture)

Single-lever operation:

CLICK HERE TO ENLARGE

The functions of the machine, such as cold and warm startup,
operation and stop, are controlled by a single lever. This makes
the operation especially comfortable and safe, because the right hand
on the handle can remain. (Similar to picture)

COMPENSATOR:

CLICK HERE TO ENLARGE

This controller in the carburettor prevents the fuel-air mixture getting richer as the air
filter becomes clogged. The correct quantity of fuel is delivered to the carburettor
depending on the quantity of air passing through the air filter. This keeps the fuel/air
ratio in the combustion mixture constant and hence also the engine power. The filter
doesn't need to be cleaned until an appreciable drop in power occurs.
(Similar to picture)

STIHL ELASTOSTART:

CLICK HERE TO ENLARGE

STIHL ElastoStart reduces the shock caused by the compression of the engine
during starting. The compression shock is taken away from the user's joints and
muscles through a spring or rubber element in the starter handle.
(Similar to picture)

MANUAL FUEL PUMP (PURGER):

CLICK HERE TO ENLARGE

A small fuel pump delivers fuel to the carburettor at the touch of a button.
This reduces the number of starting strokes required following extended
breaks in operations.
(Similar to picture)
